TGM 160 vertical roller mill with the patent number of ZL 200520030288.3, based on the design of Raymond Mill, has passed the quality certification and CE certification. The vertical roller mill is widely used in the fields of cement, electricity, steel, nonmetallic ore, etc., it can grind cement raw materials, slag, coal, etc. into powder.
Benefit from tgm 160 vertical roller mill
- 20-50% less energy use than ball mill systems
- For portland cement, slag and blended cements
- High productivity with stable, reliable operation
- Easy maintenance; low maintenance costs
- Effective drying when grinding blast furnace slag or blended cements with wet components
- Consistent cement quality with easy-to-adjust quality parameters
- Long lifetime
- Simple, compact layout
- Proven technology
Technical data of tgm 160 vertical roller mill
Roller piece: 6
Roller Diameter×Height(mm): Ф440×270
Ring Inner Diameter×Height(mm): Ф1600×270
Speed Of Main frame (r/min): 82
Max. Input Size (mm): 35
Product Size (mm): 1.6～0.045 fineness can reach to 0.038
Capacity (t/h): 13～22
Overall Dimension (mm): 12550×5700×8355
Weight (t): 35
