TGM 100 grinding mill is designed by our company with more than 20 years’ experience, and is the ideal and suitable equipemnt for grinding in many fields, such as in electric grinding, mining, metallurgy, chemical industry, steel, building materials, coal industry and so on, and has produced great economic and social benefits.
Structure of tgm 100 grinding mill
TGM 100 grinding mill is mainly consists of main frame, speed reducer, powder concentrator, induced draught fan, dust collector, piping device, integrator, and motor, etc.The whole grinding mill line include Jaw Crusher, Bucket Elevator, Mill Deceleration Machine, Vibraing Feeder, Main Frame, Blower, Powder Concentrator, Powder Collecting System, Piping Device,and Bag Deduster.
Our TGM series grinding mill have three models, such as tgm100, tgm130, tgm160. The following is their technical data:
Item\Model | TGM100 | TGM130 | TGM160 |
Roller piece | 4 | 5 | 6 |
Roller Diameter×Height(mm) | Ф320×200 | Ф400×240 | Ф440×270 |
Ring Inner Diameter×Height(mm) | Ф980×200 | Ф1280×240 | Ф1600×270 |
Speed Of Main frame (r/min) | 130 | 98 | 82 |
Max. Input Size (mm) | 25 | 30 | 35 |
Product Size (mm) | 1.6~0.045 fineness can reach to 0.038 |
1.6~0.045 fineness can reach to 0.038 |
1.6~0.045 fineness can reach to 0.038 |
Capacity (t/h) | 3~8.8 | 6~13 | 13~22 |
Overall Dimension (mm) | 9910×5365×8310 | 7910×7000×9645 | 12550×5700×8355 |
Weight (t) | 16 | 26.1 | 35 |
