Tracked Cone Crusher

Tracked Cone Crusher Introduction

Tracked Cone Crusher is another kind of mobile crushing unit, mainly to satisfy different requirement of final products. Tracked Cone Crusher replaces impact crusher to produce much harder and fine stone or sand products. According to actual needs, Tracked Cone Crusher can be adjusted to different crushing chamber. It expands the using area of medium-coarse crushing cone crusher mobile crushing station.

Tracked Cone Crusher

Tracked Cone Crusher Featuer

(1) Unit and equipment installation integration, the whole coordination strong, layout reasonable and compact, these save time and space for site operation, increase flexibility, while eliminating a lot of space infrastructure, greatly reducing the investment costs.

(2) The unit trailer chassis is higher, the body width is less than operation semi-trailer, and turning radius is small, easy to drive under the environment of rugged poor road in the broken ground.

(3) Cone crusher configured not only has the function of fine crushing, but also directly output mid-fine granularity finished, fully functional, which directly reduces the cost of shipping materials. In addition, longer units can directly transfer the broken material into the Transport carriages, to facilitate the timely transportation.

(4) Cone crusher adopts static pressure principle, by the second vibration isolation, equipment vibration is little, more conducive to the implementation of the installation.

(5) The material layer of cone crusher has more efficient, and job stability, also saves much time to a great extent.

(6) Equipment configures flexibility, can be stand-alone group to produce independently, and also be composed of coarse crushing equipment associated with the operation. The diesel generator in unit not only supplies the power to unit, but also supplies targeted power to process system configuration unit, greatly improving the adaptability of the equipment.

(7) Technology is mature, operation and maintenance is easy. Unit configured devices are clear in division, concise, easy to maintain.

Tracked Cone Crusher

Tracked Cone Crusher Application

The Tracked Cone Crusher(mobile crushing and screening plants) is applied to multistage crush large materials, and then screen the discharges according to their different specifications. The whole set plants is widely used to mine, building material, highway, rail way and hydropower industries, etc, finish crushing and screening operations at one time, produce required size and output for consumers.

Tracked Cone Crusher Technical Data

Specifications:
Model YCS160L YHP220L
Equipment Configuration Crusher Cs160 Hp220
Belt Type Vibrating Feeder GLD-12×4/15 GLD-15×4/15
Volume of Upper Hopper 5 5
Height of Final Products Receiving 3100 3100
Model of Main Belt Conveyor B1000×9M B1000×9M
Genset (Kw) 270 330
Transportation Length (mm) 12500 12500
Transportation Width (mm) 3240 3240
Working Height (mm) 3900 3900
Working Weight (t) 36.2 41.4
