Ball mill is an efficient tool for grinding many materials into fine powder. The Ball Mill is used to grind many kinds of mine and other materials, or to select the mine. Ball mill is widely used in building material, chemical industry, etc. There are two ways of grinding: the dry way and the wet way. It can be divided into tabular type and flowing type according to different expelling mine.
Ball Mill Technical Specifications
| Model | Speed of bucket (r/min) | Size of feed opening (mm) | size of outputting feed (mm) | Production (t/h) | Power (kW) |
| Ф900×1800 | 42 | ≤20 | 0.075-0.89 | 0.65-2 | 18.5 |
| Ф900×3000 | 41 | ≤20 | 0.075-0.89 | 1.1-3.5 | 22 |
| Ф1200×2400 | 36 | ≤25 | 0.075-0.6 | 1.5-4.8 | 30 |
| Ф1200×3000 | 32 | ≤25 | 0.075-0.4 | 1.6-5 | 45 |
| Ф1200×4500 | 32 | ≤25 | 0.075-0.4 | 1.6-5.8 | 55 |
| Ф1500×3000 | 31 | ≤25 | 0.075-0.4 | 2-7 | 75 |
| Ф1500×4500 | 27 | ≤25 | 0.075-0.4 | 3.5–8 | 110 |
| Ф1500×5700 | 27 | ≤25 | 0.075-0.4 | 3.5-10 | 132 |
| Ф1830×3000 | 26 | ≤25 | 0.075-0.4 | 4-12 | 160 |
| Ф1830×6400 | 26 | ≤25 | 0.075-0.4 | 6.5-15 | 210 |
| Ф1830×7000 | 26 | ≤25 | 0.075-0.4 | 6.5-22 | 210 |
| Ф2200×5500 | 21 | ≤25 | 0.075-0.4 | 10-22 | 370 |
| Ф2200×6500 | 21 | ≤25 | 0.075-0.4 | 14-50 | 380 |
| Ф2200×7500 | 21 | ≤25 | 0.075-0.4 | 16-50 | 380 |
| Φ2200×9500 | 21 | ≤25 | 0.074-0.4 | 18-60 | 475 |
We are professional and large grinding mill manufacture, and supply various type and model grinding mill machines. We can design specific equipment according to customers needs. So if you want to know more about our product, please contact us, and tell us your actual needs, we will help select the best suitable equipment.
Spodumene: According to the hard rock crushing process, the crushed product is generally 5-40mm, combined with different design requirements of customers, two-end or three-stage crushing, high-grade crushed products (above 4-5%) can be directly used in the metallurgical process to produce lithium carbonate Or lithium hydroxide, the particle size of the finished product is generally around 20-40mm; low-grade generally requires ball mill grinding and separation, and the particle size of the finished product is generally around 5-20mm;
