Primary and secondary jaw crusher technical parameters

PE Series Jaw Crusher is the newest primary and secondary crusher which most widely used in primary  and secondary crushing. It absorbs first-class technology from foreign, and develops the technology in the further. It is widely used in primary crushing of building material, metallurgy, mining, railway, chemical industries and water conservancy etc. Almost all of the mineral ore are able to crush, such as coal, limestone, cement, dolomite, quartz, feldspar, fluorite, gypsum, granite, calcite etc.

Primary and secondary jaw crusher technical parameters

Primary and secondary jaw crusher working principle

The strip and strip pulley are driven by a motor, and the moving jaw moves up and down via eccentric shaft. The angle between fixed jaw and moving jaw becomes smaller when the moving jaw runs down, then the materials are crushed into pieces. It will become bigger when the moving jaw runs up. The moving jaw board leaves the fixed jaw board under the action of pole and spring, and then the end products come out from the crushing cavity. And also, Jaw crusher is always used as the primary and secondary crusher.

Primary and secondary jaw crusher technical parameters

Model Max. Feeding Size (mm) Discharge Size (mm) Capacity (t/h) Motor Power (kW) Weight (t)
PE250×400 200 20-60 5-20 15 2.8
PE400×600 350 40-100 15-60 30 6.5
PE500×750 425 50-100 50-100 55 10.3
PE600×900 480 65-160 60-130 75 16.5
PE750×1060 630 80-140 100-250 110 29
PE900×1200 750 95-165 160-380 110 54.5
PE1000×1200 850 195-265 315-550 110 57
PE1200×1500 1020 150-300 300-800 160-220 100.9
PEX250×750 210 25-60 10-40 22 5
PEX250×1000 210 25-60 15-50 30 6.5
PEX250×1200 210 25-60 20-60 37 7.7
